Rapid-Air Powered Stock Straighteners
Specifications
| Series |
Model |
Price |
| SA |
SA3 |
$4,655.00 |
| SA3M |
$4,940.00 |
| SB |
SB4 |
$4,940.00 |
| SB4M |
$5,225.00 |
| SBX |
SBX4 |
$5,605.00 |
| SBX8 |
$6,555.00 |
| SBX12 |
$7,505.00 |
| SBX4M |
$5,985.00 |
| SBX8M |
$6,935.00 |
| SBX12M |
$7,885.00 |
| SCX |
SCX6 |
$7,125.00 |
| SCX12 |
$8,550.00 |
| SCX18 |
$13,110.00 |
| SCX24 |
$17,860.00 |
| SCX6M |
$9,500.00 |
| SCX12M |
$10,925.00 |
| SCX18M |
$15,485.00 |
| SCX24M |
$20,235.00 |
| SCX6H |
$10,450.00 |
| SCX12H |
$11,875.00 |
| SCX18H |
$16,435.00 |
| SCX24H |
$21,185.00 |
| SD |
SD6 |
$9,500.00 |
| SD12 |
$10,925.00 |
| SD18 |
$15,485.00 |
| SD24 |
$20,235.00 |
|
|
|
 |
|
|
Rapid-Air Stock Straightener Specifications
| Model |
Max. Material
Width |
Effective
Straightening
Range |
Max. Speed
in. / min. |
AC Input Power
Required |
SA Standard Speed
SA3
|
3" |
.002" - .030" |
700 |
1/4 HP, 115vac, 1ph |
SA Medium Speed
SA3M
|
3" |
.002" - .030" |
1400 |
1/2 HP, 115vac, 1ph |
SB Standard Speed
SB4
SB4M
|
4"
4" |
.003" - .050"
.003" - .050" |
700
1400 |
1/2 HP, 115vac, 1ph
1/2 HP, 115vac, 1ph |
SBX Standard Speed
SBX4
SBX8
SBX12 |
4"
8"
12" |
.004" - .090"
.004" - .085"
.004" - .075" |
825
825
825 |
3/4 HP, 115vac, 1ph
3/4 HP, 115vac, 1ph
3/4 HP, 115vac, 1ph |
SBX Medium Speed
SBX4M
SBX8M
SBX12M |
4"
8"
12" |
.004" - .090"
.004" - .085"
.004" - .075" |
1650
1650
1650 |
1 HP, 115vac, 1ph
1 HP, 115vac, 1ph
1 HP, 115vac, 1ph |
SCX Standard Speed
SCX6
SCX12
SCX18
SCX24 |
6"
12"
18"
24" |
.006" - .100"
.006" - .090"
.006" - .080"
.006" - .065" |
825
825
825
825 |
1 HP, 115vac, 1ph
1 HP, 115vac, 1ph
1 HP, 115vac, 1ph
1 HP, 115vac, 1ph |
SCX Medium Speed
SCX6M
SCX12M
SCX18M
SCX24M |
6"
12"
18"
24"
|
.006" - .100"
.006" - .090"
.006" - .080"
.006" - .065" |
1650
1650
1650
1650 |
2 HP, 230vac, 1ph
2 HP, 230vac, 1ph
2 HP, 230vac, 1ph
2 HP, 230vac, 1ph |
SCX High Speed
SCX6H
SCX12H
SCX18H
SCX24H |
6"
12"
18"
24" |
.006" - .080"
.006" - .070"
.006" - .060"
.006" - .055" |
4100
4100
4100
4100 |
3 HP, 230vac, 1ph
3 HP, 230vac, 1ph
3 HP, 230vac, 1ph
3 HP, 230vac, 1ph |
SD Standard Speed
SD6
SD12
SD18
SD24 |
6"
12"
18"
24" |
.006" - .125"
.006" - .125"
.006" - .100"
.006" - .090" |
825
825
825
825 |
2 HP, 230vac, 1ph
2 HP, 230vac, 1ph
2 HP, 230vac, 1ph
2 HP, 230vac, 1ph |
SC Standard Speed
SC4 |
4" |
.015" - .085" |
825 |
1 HP, 115vac, 1ph |
|
